INSTALLER/SERVICEMAN
DIRECT VENT
Model Number CWL-85DV CWL-100DV CWL-110DV
B
urner Type Beckett Beckett Beckett
Burner Model AFII 100 AFII 100 AFII 100
Nozzle Type .75 60°B .85 60°B 1.00-60°ES
Pump Pressure PSI 140 140 140
Head/Pin Position 45
Air Band N/A N/A N/A
Air Shutter 4.5 5.0 7
Draft Over Fire 0 to +.1" 0 to +.1" 0 to +.1"
Draft In Stack -0.02" -0.02" -0.02"
CO
2
Reading 10-11.5% 10-11.5% 10-11.5%
Smoke Reading ZERO ZERO ZERO
AFII 100 DIRECT VENT SERIES: CWL 85 HAGO B
CWL 100 HAGO B
CWL 110 HAGO ES
NOTICE:
Above settings are approximate. Final adjustments to
be made with proper test equipment. Be sure all oil lines are
air free and the use of flare fittings is recommended. See
installation/service manual for detailed information.
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
INSTALLER/SERVICEMAN
M
odel Number CWL-85 CWL-100 CWL-110
Burner Type Beckett Beckett Beckett
Burner Model AFII 100 AFII 100 AFII 100
Nozzle Type .75 60°B .85 60°B 1.00-60°ES
Pump Pressure PSI 140 140 140
Head/Pin Position 45 7
Air Band N/A N/A N/A
Air Shutter 4.5 5.0 7
Draft Over Fire 0 to +.1" 0 to +.1" 0 to +.1"
Draft In Stack -0.02" -0.02" -0.02"
CO
2
Reading 10-11.5% 10-11.5% 10-11.5%
Smoke Reading ZERO ZERO ZERO
AFII 100 DIRECT VENT SERIES: CWL 85 HAGO B
CWL 100 HAGO B
CWL 110 HAGO ES
NOTICE:
Above settings are approximate. Final adjustments to
be made with proper test equipment. Be sure all oil lines are
air free and the use of flare fittings is recommended. See
installation/service manual for detailed information.
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
INSTALLER/SERVICEMAN
Model Number CWL-85 CWL-100 CWL-110
Burner Type Beckett Beckett Beckett
Burner Model AFG AFG AFG
Nozzle Type .75 70B .85 80A 1.00 80A
Pump Pressure PSI 140 140 140
Head/Pin Position F-3 F-4 F-6
Air Band 33 5
Air Shutter 34 5
Draft Over Fire 0 to +.1" 0 to +.1" 0 to +.1"
Draft In Stack -0.02" -0.02" -0.02"
CO
2
Reading 10-11.5% 10-11.5% 10-11.5%
Smoke Reading ZERO ZERO ZERO
Hago nozzle can be substituted
Equipped with Oil Delay Valve on all models
NOTICE
Above settings are approximate. Final adjustments to be made
with proper test equipment. Be sure all oil lines are air free and
the use of flare fittings is recommended. See installation/ser-
vice manual for detailed information.
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
26
