TK 3.95 Diesel Engine Specifications (Rev 1/97)
21
Crankshaft and Crankshaft Bearings (continued)
Rod Bearing Inside Diameter
Standard 1.5753-1.5759 in. (40.013-40.029 mm) 1.5772 in. (40.060 mm)
Undersize 1.5655-1.5661 in. (39.763-39.779 mm) 1.5673 in. (39.810 mm)
Rod Bearing Clearance .0013-.0023 in. (0.033-0.059 mm) .0059 in .(0.150 mm)
End Play .0035-.0107 in. (0.090-0.271 mm) .0130 in .(0.330 mm)
Deflection .0008 in. (0.020 mm)
Cylinder Block
Cylinder Inside Diameter
Standard 2.8346-2.8358 in. (72.000-72.030 mm) 2.8425 in. (72.200 mm)
1st Oversize 2.8445-2.8457 in. (72.250-72.280 mm) 2.8524 in. (72.450 mm)
2nd Oversize 2.8543-2.8555 in. (72.500-72.530 mm) 2.8622 in. (72,700 mm)
Cylinder Roundness 0-.0004 in. (0-0.010 mm) .0012 in. (0.030 mm)
Deck Distortion .002 in. (0.05 mm)
Cylinder Head
Distortion 0-.002 in. (0-0.05 mm) .006 in. (0.15 mm)
Timing Gears
Timing Gear Lash
Crankshaft Gear to Idler Gear .0016-.0047 in. (0.040-0.120 mm) .0079 in. (0.200 mm)
Crankshaft Gear to Oil Pump Gear .0043-.0075 in. (0.110-0.190 mm) .0079 in. (0.200 mm)
Idler Gear to Camshaft Gear .0016-.0047 in. (0.040-0.120 mm) .0079 in. (0.200 mm)
Idler Gear to Fuel Injection Pump
Gear .0016-.0047 in. (0.040-0.120 mm) .0079 in. (0.200 mm)
Idler Gear Bushing Inside Diameter .7874-.7882 in. (20.000-20.021 mm) .7906 in .(20.080 mm)
Idler Gear Shaft Outside Diameter .7858-.7866 in. (19.959-19.980 mm) .7846 in. (19.930 mm)
Idler Gear Shaft to Idler Gear Bushing
Clearance .0008-.0024 in. (0.020-0.062 mm) .0059 in. (0.150 mm)
Oil Pump
Type Trocoid
Outer Rotor to Pump Body Clearance .0039-.0063 in. (0.100-0.160 mm) .0098 in. (0.250 mm)
Inner Rotor Tip to Outer Rotor Lobe
Clearance .0059 in. (0.150 mm)
Rotor Plate to Rotor Clearance .0012-.0035 in. (0.030-0.090 mm) .0051 in. (0.130 mm)
Rotor Shaft to Rotor Shaft Bore
Clearance .0005-.0017 in. (0.013-0.043 mm) .0079 in. (0.200 mm)
Pressure Control Valve Setting 42.7-56.9 psi (294-392 kPa)
