Torque Values for TK 2.49 & TK 3.74 Engines
Description
Dia. x Pitch
(mm)
N•m ft-lb kgm
Camshaft Thrust Plate Mtg. Bolt 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Connecting Rod Bolt 7x1 22.6-27.5 16.6-20.3 2.3-2.8
Crankshaft Pulley Bolt 12x1.25 83.4-93.2 61.5-68.7 8.5-9.5
Cylinder Head Mtg. Bolt 8x1.25 37.3-41.2 27.5-30.4 3.8-4.2
Engine Lift Bracket Mtg. Bolt 8x1.25 22.6-28.4 16.6-21.0 2.3-2.9
Exhaust Manifold Stud 8x1.25 22.6-28.4 16.6-21.0 2.3-2.9
Exhaust Manifold Mtg. Stud 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Exhaust Manifold Mtg. Nut 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Flywheel Mtg. Bolt 10x1.25 80.4-86.3 59.3-63.7 8.2-8.8
Fuel Injection Nozzle Assy. 20x1.5 49.0-53.0 36.2-39.1 5.0-5.4
Fuel Injection Nozzle Nut 49.0-53.0 36.2-39.1 5.0-5.4
Fuel Injection Pump Mtg. Nut 8x1.25 22.6-28.4 16.6-21.0 2.3-2.9
Fuel Injection Pump Mtg. Stud 8x1.25 22.6-28.4 16.6-21.0 2.3-2.9
Fuel Injection Pump Inspection Plate Nut 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Fuel Injection Pump Inspection Plate Stud 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Fuel Injection Pump Gear Case Mtg. Bolt 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Fuel Injection Pump Air Bleed Screw Assy. 12 24.5-34.3 18.1-25.3 2.5-3.5
Glow Plug 10x1.25 14.7-19.6 10.8-14.5 1.5-2.0
Idler Gear Shaft Mtg. Bolt 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Intake Manifold Mtg. Bolt 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Main Bearing Bolt 9x1.25 52.0-55.9 38.3-41.2 5.3-5.7
Oil Intake Pipe Mtg. Bolt 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Oil Pan Mtg. Bolt 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Oil Pan Cover Mtg. Bolt 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Oil Pump Mtg. Bolt 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Rear Seal Housing Mtg. Bolt 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Rocker Arm Support Mtg. Bolt 8x1.25 22.6-28.4 16.6-21.0 2.3-2.9
Rocker Arm Support Mtg. Nut 8x1.25 22.6-28.4 16.6-21.0 2.3-2.9
Rocker Arm Support Mtg. Stud 8x1.25 22.6-28.4 16.6-21.0 2.3-2.9
Starter Mtg. Bolt 12x1.75 78.5-98.1 57.9-72.3 8.0-10.0
Starter Mounting Flange Mtg. Bolt 10x1.5 44.1-53.9 32.5-39.8 4.5-5.5
Thermostat Housing Mtg. Bolt 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Timing Gear Housing Mtg. Bolt 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Timing Gear Housing Inspection Cover
Mtg. Bolt 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Timing Gear Cover Mtg. Bolt 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Timing Gear Cover Inspection Cover Bolt 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Valve Cover Mtg. Nut 8x1.25 22.6-28.4 16.6-21.0 2.3-2.9
Water Pump Mtg. Bolt 8x1.25 22.6-28.4 16.6-21.0 2.3-2.9
Water Pump Pulley Mtg. Nut 6x1 9.8-11.8 7.2-8.7 1.0-1.2
Water Pump Pulley Mtg. Stud 6x1 9.8-11.8 7.2-8.7 1.0-1.2
