Drawings and Parts Listing
On the following pages, the reader will find technical drawings and corresponding
parts listings of the HS3E and HS4E machines. The technical drawing illustrating
a particular sub-assembly or area of the machine provides the individual parts for
that sub-assembly or area. A complete listing of available parts is provided at
the end of this chapter.
The reader will find that the technical drawings and corresponding parts listings
are arranged by category. Those categories in order are:
1. Electrical
2. Mechanical
3. Parts listing
