19
Topside Control Panel
Main Control Panel
Button Functions:
Pump 1 Button: Press once to turn Pump 1 on low speed; a second time for high
speed; a third time to turn off.
Pump 2 Button (if equipped): Press once to turn Pump 2 on; press again to turn
off.
Light Button: Turns light(s) on and off. By continually pressing the button on and
off, you can cycle through the colors.
Warm/Cool Button: Press continuously to increase or decrease water
temperature, one degree at a time. Functions as both a warmer or cooler button.
Indicator Lights:
Smart Winter Mode (SWM) Indicator: When the feature is actived the indicator
light is lit, page 23.
Pump Indicator: When a pump is activated the indicator light is lit, page 20.
Light Indicator: When the underwater light is turned on the indicator light is lit,
page 20.
Filter Indicator: When a lter or purge cycle is running the Filter Indicator light is
lit, page 22.
Heater Indicator: Whenever the spa is heating the Heater Indicator light is lit, page
20.
Note: Temperature range is from 59° to 104°F (15° to 40°C).
Set Point Indicator: Whenever the “set temperature” is displayed on the LCD
dislay, the Set Point Indicator will be lit.
Air Indicator: This feature is not available.
1 2
1 2
102
1
2
1
2
Topside Control Panel
