Thetford C262CWE - C263 CS Floor and Wall Connections

17
C263CS
Floor
The C260 must be screwed to a flat and stable floor
Angle back wall
-
floor
8.2
8.28.2
8.2 Fl
FlFl
Floor connection
oor connectionoor connection
oor connection
Mount the toilet to the floor with four screws.
Screw type
Screws are supplied by Thetford
Screw positions
See the installation drawing of the applicable toilet (1.4)
Required torque
1.2 ± 0.3 Nm for a Plywood floor
Torque may differ if the floor is made from a different material.
8.3
8.38.3
8.3 Wall connection
Wall connectionWall connection
Wall connection
This toilet is mounted to the outside wall with a wall bracket.
Install the wall bracket with two screws to the outside wall.
Screw positions
See
the
installation drawing of
the
applicab
le toilet (
1.4)
Required torque
0.
5
Nm
