Thetford C402C User Manual

No level indication of the
C402X Water tank
Replace the Reed
switch of the water
tank
(part 32330-62)
Check if the LED
functions by putting
a magnet in front of
the reed switch
No
Check if the float
box is well placed
and the float is
moving easily
Check if the holding
tank is well
positioned
Reposition or put a
new float box in place
(part 32330-62)
No
Yes
Yes
Remove the handle
and control panel to
check if the cables
are well connected
Connect the cables
correctly
No
Yes
6.201 3/5 05/09

Thetford C402C Specifications

General

Type	Cassette Toilet
Flush Water Tank Capacity	15 liters
Dimensions (H x W x D)	512 x 670 x 400 mm
Weight	8.2 kg
Flush System	Electric
Level Indicator Waste Tank	Yes
Level Indicator Flush Water Tank	Yes
Removable Cassette	Yes
Ventilation	Yes
Battery Operated	Yes
Toilet Seat Rotation	Yes
Waste Holding Tank Capacity	19.3 liters
