RV Installation Instructions continue on Page 5.
Installation
RV Model
1. Install the two closet bolts in closet ange.
2. While holding bolt up so the head touches underside
of closet ange, install one nut on each bolt and screw
nuts down until they
touch top of gauge. If
gauge is misplaced,
bottom surface of
nuts should be 1.34
in. (3.4 cm) above
oor.
5. Place unit on closet ange and locate position for plastic
locator disc by tracing around one of the front legs. Drill
5/32” dia. hole in oor and fasten disc to oor with at
sides oriented as shown. Use #10 screw provided.
Important: This disc prevents toilet from moving on
floor.
6. Lower toilet onto closet ange until nuts on closet bolts
go through rectangular holes in metal brackets, seal rests
on closet ange, and leg locates over locating disc.
4.
Make sure white
f o r k - s ha p e d
slides are in
forward posi-
tion.
3. Turn the toilet upside-down and install closet ange seal
on Slide-EZ Valve with at side against toilet.
Electrical Hookup
RV and Marine Models
Connect your 12-Volt or 24-Volt model Electra Magic
directly to the appropriate D.C. source as a separate circuit.
Use minimum size #14 gauge wire. (Black wire to positive
[hot], white to negative [ground].)
Important – Be sure polarity of power supply has been
properly determined and correctly connected to lead wires
before operating.
