Thetford ELECTRA MAGIC - RV Slide-EZ Valve Parts

7
RV Slide-EZ Valve
Key Part
No. No. Description
1 12836 Slide-EZ Valve
2 03911 Handle*
3 03913 Retaining Ring
4 08637 Slides (2)
5 08737 Screw (4)
6 24304 Flange Seal
7 02690 Nut (2)
8 12525 Closet Bolt (2)
9 08636 Mtg. Bracket (2)
10 12838 Mounting Package
(comprised of Key
Parts 4-9)
Note: Slide-EZ Valve No. 03632 is
used on pre-1978 toilets. Toilets
manufactured in 1978 or later use an
ABS-Slide EZ Valve No. 12836.
Record Your Product ID Information Here
MODEL :
PART NO :
CODE :
(See Parts List on Pg. 6 for location
of Product ID Label)
(For Service/Part info, call 1-800-521-3032)
Key Part
No. No. Description
1 03940 Sump Assy.
2 08637 Slides (2)
3 01663 Screw (4)
4 12984 Acorn Nut (2)
5 12983 Bolt (2)
6 08636 Mtg. Bracket (2)
7 05063 Mounting Package
(comprised of Key
Parts 2-6)
