Installation
9
Installation
10
Step3: Lift and hang the inverter on the wall,lock the nuts, and fix the machine.
Fig.2.6
2.4 Electrical Connection
2.4.1 System Wiring Diagram
General wiring diagram of EPH series hybrid inverter.
Fig.2.7
2.4.2 Overview Of The Electrical Connecting Part
Fig.2.8
2.4.3 PV Connection
2) The voltage, current and power ratings of the PV strings are within the allowable range
of the inverter. Please refer to the Technical Data Sheet for voltage and current limits
Before connecting PV panels/strings to inverter, please make sure:
1) Use the right PV connectors in the accessory box.
.
3) Make sure the PV switch of the inverter is in the “OFF” position during wiring.
4) PV strings could
not conne
ct to EARTH conductor.
STEP1:
Assemble the PV connectors from the accessory box.(PV cable must be firmly crimped
into connectors)
BMS
ON
OFF
PV1
+
-
PV2
Battery
+
-
+
-
Meter
DRED
WIFI
Power
Back-up On-Grid
Fig.2.9
STEP2:
Connect the PV connectors to the inverter. There
will be a click sound if connectors are inserted correctly
into PV plugs.
Fig.2.10
