Thinkware BAB-50 - Install Constant Power Cable

12
Wiring diagram
Refer to the following wiring diagrams to correctly connect the product.
Cigarette lighter socket
BAB-50
External
battery
GND
B+
ACC OUT
DASH CAM
BAB-50
External
battery
CHASSIS GND
Fuse box
ACC
GND
GND
B+
ACC IN
ACC OUT
DASH CAM
BAB-50
External
battery
BAB-50
External
battery
CHASSIS GND
CHASSIS GND
Fuse box
ACC
Fuse box
ACC
GND
GND
GND
B+
ACC IN
ACC IN
ACC OUT
DASH CAM
Caution
When charging a battery that is overly discharged or left unused for a long time, the black box will power
on after reaching a stable output voltage using the trickle charging function, which gradually charges
the battery to protect the battery cells. (It may take up to 5 minutes to supply power.)
When connecting the product using the charging cable for the cigarette lighter socket
When connecting the product using the charging cable for the fuse box
When connecting two products in parallel using the charging cable for the fuse box
