8 Plug and connection assignment
This chapter will help you select the right cables and plugs to connect your valuable
equipment in such a way that a perfect sound experience is ensured.
Please note these advices, because especially in ‘Sound & Light’ caution is indicated:
Even if a plug ts into the socket, an incorrect connection may result in a destroyed
power amp, a short circuit or ‘just’ in poor transmission quality!
1 Signal
2 Ground, shielding
1 Signal (left)
2 Signal (right)
3 Ground
Introduction
1/4" TS phone plug (mono, unbal‐
anced)
1/4" TRS phone plug (stereo, unbal‐
anced)
Plug and connection assignment
MPS-1000
31
