Mounting the drum module on the rack
1. Insert the D-sub plug of the multiple cable (21) into the provided socket on the bottom side of the drum module.
2. Tighten the D-Sub plug with the hand screws (25).
3. Put the drum module (20) up to the stop into the free bracket of the left crossbeam (7).
4. Align the module and tighten the wing nut of the bracket.
Position bass drum and hi-hat pedal
1. Place the pedal with the bass drum pad centred under the rack. Position the bass drum pedal centred in front of the pad.
2. Place the Hi-hat pedal left of the bass drum pad.
Set-up and cabling
Set up the rack, the pads and the cymbals according to your needs. Finally, position the pedal with the bass drum pad and the Hi-
hat pedal in front of the rack and connect all trigger cables to the e-drum module.
Assembly
e-drum set
12
