3 Assembly
Overview
Loosen the screws of the clamps before sticking the tubes together. Mount the various elements in the specied sequence. The
nal positions of the components are shown in the illustration below.
12 Hi-hat pad (10 inch)
13 Crash (12 inch), Ride (12 inch)
14 Tom pad 1 (8 inch), tom pad 2 (8 inch)
15 Snare pad (10 inch)
16 Bass drum pad (8 inch)
17 Bass drum pad pedal
19 Hi-hat pedal
20 e-drum module Millenium MPS-450
Assembly
MPS-450
7
