Range Meaning
Display area The waveform of input and output channels is graphically displayed. Use the radio buttons ‘Inx’ and
‘Outx’ to determine the inputs and outputs to be displayed.
Control area Drag the faders with the mouse to adjust the levels for the input and output channels. The ‘Mute’
button mutes or unmutes the respective channel. The ‘Normal’ / ‘Inverse’ button inverts the phase of the
respective channel by 180° when needed.
Operating on the computer
digital speaker management system
24
