8 Plug and connection assignment
This chapter will help you select the right cables and plugs to connect your valuable equip‐
ment in such a way that a perfect sound experience is ensured.
Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a
plug ts into the socket, an incorrect connection may result in a destroyed power amp, a short
circuit or ‘just’ in poor transmission quality!
1 Signal (in phase, +)
2 Signal (out of phase, –)
3 Ground
Introduction
1/4" TRS phone plug (mono, bal‐
anced)
Plug and connection assignment
digital speaker management system
38
