Front panel
1 LEDs [1], [2], [3], [4]
The LED lights up when a signal is present at the respective input.
2 Inputs [CH 1] … [CH 4], designed as 1/4" phone jack (mono, balanced).
3 [USB]
USB port
4 [POWER]
This LED lights when the device is turned on.
Rear panel
5 [SPEAKER OUTPUT]
Screw terminal strip
6 [PASSIVE OUTPUT]
Outputs [CH 1] … [CH 4], designed as 1/4" phone jack (mono, balanced).
7 Power cord
Connections and controls
DSP 4x4 Mini Amp
17
