THOMSON BB-3THB - Bluetooth and External Connections; Bluetooth Pairing and Playback; Earphone Jack Usage

7
REMOVING USB/SD DEVICE
TO REMOVE THE USB/SD DEVICE, SWITCH THE FUNCTION MODE TO OTHER MODE (RADIO OR TAPE) FIRST,
THEN UN-PLUG THE USB/SD DEVICE BY PULLING OUT FROM THE SOCKET DIRECTLY.
BLUETOOTH CONNECTION
- SWITCH FUNCTION SWITCH TO SELECT MUSIC MODE (PRESS MODE BUTTON TO SELECT
BLUETOOTH MODE IF USB/SD DEVICE IS PLUGGED IN), LED INDICATOR WILL FLASH
RAPIDLY IN BLUE COLOUR DURING CONNECTION. THEN THE UNIT IS READY TO PAIR WITH
YOUR BLUETOOH DEVICE (SUCH AS MOBILE PHONE).
- SWITCH ON THE BLUETOOTH FUNCTION OF YOUR BLUETOOH DEVICE AND SELECT
“Thomson BB-3THB” BLUETOOTH EQUIPMENT FOR CONNECTION.
- AFTER YOUR BLUETOOH DEVICE IS CONNECTED WITH THE UNIT VIA BLUETOOTH, LED
INDICATOR WILL STAY BLUE COLOUR, START TO PLAYBACK YOUR DEVICE, OR PRESS PLAY
BUTTON ON THE UNIT.
- DURING BLUETOOTH PLAYBACK, LED INDICATOR WILL FLASH IN BLUE COLOUR.
EARPHONE JACK
- THIS SYSTEM CAN BE CONNECTED WITH HEADPHONE OR EXTERNAL AMPLIFIER /
SPEAKER BY 3.5MM EARPHONE JACK.
Technical Specification
Batteries
D-Size 1.5V x 4
FM range
88MHz to 108MHz
AM range
530KHz to 1600KHz
USB/SD Maximum capacity
16GB
USB/SD Playback file format
MP3, WMA
Recording file format
MP3, 128kbps
Headphone input:
dia. 3.5mm
Dimensions (mm)
312 (W) x 109 (D) x 120 (H)
Weight
1.22kgs
Power consumption
10W
Speakers
2x1.5W
NOTE: As result of continual improvements, the design and specifications of the product
within may differ slightly to the units illustrated on the packing.
