Troubleshooting tips
Troubleshooting Tips
Receiver/Tuner Operation
ST indicator is off.
• Adjust the antenna.
• Press DIGITAL INPUT/ST/MONO button to insure
you are not outputting in mono.
The signal is Mono. Severe hum or noise.
• The signal is too weak. Connect an external anten-
na.
• Adjust Antenna
• Reposition Antenna away from any electronics.
Remote Control Operation
The remote control does not operate the unit.
• Another source mode is selected on the remote.
Press the correct Source Button.
• No batteries installed. (included with your system)
Install the batteries before attempting to operate the
remote. Be sure to match the + and - ends of each
battery to the symbols shown in the remote battery
compartment.
• The batteries are weak. Replace all batteries.
• The remote is not pointed at the remote control
sensor on the main unit or there is an obstacle
between the remote and the main unit.
• The remote control is too far from the main unit,
move closer.
General
No audio.
• Make sure the speakers are connected.
• Check the input connections.
• Check the power cord connections.
• Make sure the MUTE signal on the front panel is
off.
• Make sure the digital setting (optical, coaxial or
analog) is correct.
• Check that the headphone is not inserted.
No audio from one channel.
• Check the speaker level setting.
• Check the speaker wire or external source cable
connections.
Noise occurs when the TV is turned on.
• The TV is too close to the audio system.
Specific instruments sound displaced.
• Check the connections between the receiver and
the speakers if the sound does not match the video.
• Check if the video and audio cable are correctly
inserted.
Cleaning the Exterior
• Disconnect the system from AC power before clean-
ing the exterior of the system with a soft dust cloth,
or with a slightly damp leather chamois. Never use
strong solvents.
Equipment Specifications:
AMPLIFIER SECTION:
All 5 channels: each 50W at 8 ohm. <10% THD @1
kHz
Subwoofer channel: 50w at 8Ω , <10% THD @100
kHz
Muting Attenuation: 65dB
Frequency Response: 40Hz to 20kHz +/-3dB
Signal to Noise Ratio: 65dB (Dolby digital mode)
VIDEO SECTION:
Input ( Sensitivity/ Impedance ):1Vp-p/ 75ohm
Output (Level/ Impedance): 1Vp-p/ 75 ohm
Frequency Response: 10Hz to 6MHz at +/- 3dB
Signal to noise ratio: 40dB
Crosstalk @3.58MHz: 40dB
AM TUNER SECTION:
Frequency Response: 80Hz – 2kHz +/-6dB
Usable Sensitivity: 800uV/m @ S/N 20dB
Signal to Noise: 38dB
Image Ratio: 27dB @ 1000kHz
IF Rejection: 35dB
FM TUNER SECTION:
Frequency Response: 40Hz – 15kHz +/-3dB
Quieting: 24dBu
Signal to Noise: 60dB(stereo) / 65dB(mono)
Image Ratio: 40dB
IF Rejection: 50dB
Dimensions:
Unit: 400D x 430W x 130H mm
Speaker : 115D x 116W x 175H mm
Subwoofer : 355D x 160W x 355H mm
