Controls
1 Flash Switch [FLASH OPEN] ................ 墌 pg. 34
2 Shooting Mode Dial
[PS, VIDEO, DUAL, VGA, XGA] .......... 墌 pg. 15
3 Dioptre Adjustment Control ................... 墌 pg. 8
4 Battery Release Button [BATT. RELEASE] .... 墌 pg. 7
5 •MENU Wheel [+, –, PUSH] ............... 墌 pg. 30
•LCD Monitor BRIGHT
(Brightness) Control [+, –] .................. 墌 pg. 16
6 •Power Zoom Lever [T/W] .................. 墌 pg. 22
•Speaker/Headphone Volume Control
[VOL.] .............................................. 墌 pg. 44
7 Snapshot Button
[SNAPSHOT] ................ 墌 pg. 18, 20, 24, 26, 67
8 OPEN/EJECT Switch ............................. 墌 pg. 10
9 Snapshot Mode Button [SNAP MODE] ... 墌 pg. 18
0 INDEX SCREEN Button .................. 墌 pg. 19, 49
! SNAP FRAME Button ........................... 墌 pg. 52
@ Monitor Open Button
[PUSH-OPEN] ............................... 墌 pg. 12, 16
# •Play/Pause Button [
4
/6] ............. 墌 pg. 44, 45
•High Speed Recording Button
[HIGH SPEED] .................................. 墌 pg. 28
$ •Stop Button [5] ................................. 墌 pg. 44
•FOCUS Button .................................. 墌 pg. 27
% •Fast-Forward Button [
3
] ........... 墌 pg. 44, 45
•SPOTLIGHT Button ........................... 墌 pg. 42
^ •Rewind Button [
2
] ................... 墌 pg. 44, 45
•BACKLIGHT Button .......................... 墌 pg. 42
& Power Switch
[ , , , , OFF] ........... 墌 pg. 14
* Recording Start/Stop Button .................. 墌 pg. 16
( Lock Button ......................................... 墌 pg. 14
Connectors
The connectors
)
to
w
are located beneath a cover.
) Headphone Connector [PHONE] ......... 墌 pg. 78
No sound is output from the speaker when
headphones are connected to this connector.
q External Stereo Microphone Input Connector
[MIC] .................................................. 墌 pg. 78
w Audio/Video Input/Output Connector: VMD20
Audio/Video Output Connector: VMD10
[AV] ............................. 墌 pg. 58, 59, 62, 63, 73
To connect cables to the following connectors
e
to
y
,
open the LCD monitor.
e Digital Video Connector
[DV IN/OUT: VMD20,
DV OUT: VMD10]
(i.link*) .............................. 墌 pg. 60, 61, 64, 65
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
r J Terminal/Edit Connector [JLIP (Joint Level
Interface Protocol) (EDIT)] .................... 墌 pg. 73
•Connect the editing cable when performing
Random Assemble Editing.
•Connect to a JLIP-compatible camcorder or VCR
to control it from the computer using the
provided Software.
t PC (DIGITAL STILL) Connector ............. 墌 pg. 60
y S-Video Input/Output Connector: VMD20
S-Video Output Connector: VMD10
[S-VIDEO] .................... 墌 pg. 58, 59, 62, 63, 73
Indicators
u Tally Lamp ........................................... 墌 pg. 16
i Power Lamp ........................................ 墌 pg. 16
Other Parts
o Viewfinder ............................................. 墌 pg. 8
p Lens Cover
Opens when the viewfinder is pulled out or the
LCD monitor is opened fully.
Q •Remote Sensor .................................. 墌 pg. 68
•Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
W Stereo Microphone .............................. 墌 pg. 78
E Flash ................................................... 墌 pg. 34
R Shoulder Strap Eyelets ............................ 墌 pg. 8
T Battery Pack Mount ............................... 墌 pg. 7
Y Grip Strap .............................................. 墌 pg. 8
U LCD Monitor ................................. 墌 pg. 16, 17
I Speaker ............................................... 墌 pg. 44
O Stud Hole .............................................. 墌 pg. 8
P Tripod Mounting Socket ......................... 墌 pg. 8
a MEMORY CARD Cover ....................... 墌 pg. 12
