Big Drawer
The big drawer has a maximum load of 10kg.
Pull out and install the big drawer
1. Pull out the big drawer;
2. Find the hook at the left and right sides
at the drawer bottom (shown
in the figure).
3. Hold the hook at two sides with a nose
pliers or tweezers and push it up and
out of the groove of sliding rail, and
take out the hook at the other side with
the same method.
4. Take out the drawer.
5. Install the drawer by putting the hook into
the right place.
