EXPLODED VIEW / PARTS LIST:
12
118 MS-PD118 O ring 70x67x1.5 1
119 MS-PD119 M6X30 hexagon socket cap screws, 6
washer combination
120 MS-PD120 Connecting rod 1
121 MS-PD121 Impact Piston 1
122 MS-PD122 Lip ring 1
123 MS-PD123 Impact Piston Pin 12x44 1
124 MS-PD124 M5X16 hexagon socket cap screw 6
and spring combination
125 MS-PD125 Cover for gear box 1
126 MS-PD126 Paper pad for gear box 1
127 MS-PD127 Flange hexagon screw M8X16LH 1
128 MS-PD128 Pressing plate 1
129 MS-PD129 Quill bearing NK18/20 1
130 MS-PD130 Eccentric shaft 1
131 MS-PD131 Wick 1
132 MS-PD132 Oil leveler 1
133 MS-PD133 Oil leveler leather collar 1
134 MS-PD134 Handle 1
135 MS-PD135 M6X20 hexagon socket cap screws, 4
washer combination
136 MS-PD136 Upper support plate 1
137 MS-PD137 Bearing 6205 1
138 MS-PD138 Gland 6205 1
139 MS-PD139 Shaft Retainer 1
Part SKU Description Quantity
