THOR MS-PD1002 - CYLINDER HEAT SINK AND LUBRICATION; The Cylinder Heat Sink; Filling of Impact Cylinder Lubrication

TECHNICAL MAINTENANCE:
7
The Cylinder Heat Sink
• Regularly remove dust to ensure the cylinder cooling. The gasoline post driver is
air-cooling type. If dust accumulates on the cylinder heat sink, the cooling effect will be
influenced directly, which will lead to failure of the cylinder.
Filling of Impact Cylinder Lubrication
• After working for an accumulated 50 hours, fill special lubrication (50g) for the impact
cylinder. See (figure 8, 9, and 10).
Figure 8. Figure 9.
Figure 10.
