THORENS TD160 User Manual

Fitting The Wand Tonearm®
to a
Thorens
TD160
family turntable
(TD150/165 similar)
C; Fitting The Wand Tonearm Mount
Step 1; Install the spindle into mounting plate. Set the spindle height using the protractor.
Lock in position using the nut (Classic) or grub screw (Plus).
Step 2; Position the mount using the Step 3; Tighten the three screws
protractor (Slide back and forth)
Step 4
;
Add the Lifter (Wand Plus on left / Thorens for Classic on right.
Step 5; Revert to main instructions for the remainder of the setup and enjoy!
www.thewandtonearm.com
©Sept 2016 design build listen Ltd. v2
-Arm at +2 degrees
-Arm level (nominal)
Note; We suggest
starting with the arm
level. Later adjust
upwards by ear. Up to 2
degrees up may be good.
<Spindle
< Nut
v Plate
“The improvement over the
Thorens arm is astonishing.
Detail, timing, but most of all
soundstage depth.”
Richard, Dunedin, New Zealand
Align to just below the step.
Lock with small hex key.
Lock with small hex key.
Slide up / down to set lift
Height (very fiddly!)

THORENS TD160 Specifications

General

Drive Type	Belt Drive
Speeds	33 1/3, 45 RPM
Tonearm	TP 16
Cartridge	Not included
Platter	Aluminum
Motor	AC synchronous
