a. Complete specifications may be found on the Specs tab
b. Angles of incidence other than 0° will result in phase shifts that differ from the programmed pattern. Angles of up to 10° are possible without significantly
affecting performance.
c. Frame Boost Mode (referred to as Triple Mode in the software) plays the R, G, and B channels of the video signal in succession, for an overall frame rate
of 180 Hz.
d. These retardance ranges are achievable by setting the phase stroke mode to half wave or full wave in the software.
e. HD2HP and HD3HP phase/retardance range values are for 30 °C when used with the LK220 liquid chiller.
Item # EXULUS-HD1(/M)
Panel Resolution 1920 x 1080 (Full HD)
Type Liquid Crystal on Silicon (LCoS) with Reflective Coating
Operating Wavelength 400 - 850 nm
Panel Active Area 12.5 mm x 7.1 mm
Pixel Pitch 6.4 µm
Fill Factor >93%
Reflective Coating Aluminum
Average Reflectance 75% (Typical)
Phase / Retardance Range 2π at 633 nm (Standard Mode); 4.7π at 532 nm (Extended Mode)
Angle of Incidence
a
0°
Optic Axis 45°
Reflected Wavefront Distortion <λ/7 @ 633 nm
Damage Threshold
CW
b
5 W/cm (532 nm, Ø0.0107 mm)
Pulsed (ns)
0.63 J/cm
2
(532 nm, 8.6 ns, 10 Hz, Ø203 µm)
Pulsed (fs)
0.138 J/cm
2
(535 nm, 59.4 fs, 100 Hz, Ø188 µm)
Frame Rate
60 Hz (Standard Mode); 180 Hz
(Frame Boost/Triple
c
)
Fluctuation / Flickering (RMS)
d
<1% (Standard Mode); <5% (Extended Mode)
Beam Deviation Using Panel Tip / Tilt ±3.2°
Trigger Output
e
None
Trigger Output High Voltage Level N/A
Trigger Output Pulse Width N/A
Dimensions (L x W x H)
f
172.0 mm x 110.0 mm x 81.6 mm (6.77" x 4.33" x 3.21")
Weight 1.24 kg (2.73 lbs)
Storage Temperature 0 °C to 60 °C (32 °F to 140 °F)
Operating Temperature
g
10 °C to 40 °C (50 °F to 104 °F)
PC Connection
HDMI-Compatible Connector
USB 2.0 Connector
Bit Depth 8 Bit, 0 - 255 Gray Level
a. Other angles of incidence will result in phase shifts that differ from the programmed pattern. Angles of up to 10°
are possible without significantly affecting performance.
b. The power density of your beam should be calculated in terms of W/cm. For an explanation of why the linear
power density provides the best metric for long pulse and CW sources, please see the Damage Thresholds tab.
c. Frame Boost Mode (referred to as Triple Mode in the software) plays the R,G, and B channels of the video signal
in succession, for an overall frame rate of 180 Hz.
d. Fluctuation / Flickering is the phase fluctuation as the percentage of the entire phase range and is dependent on
current phase setting. The value stated is the maximum fluctuation and typically occurs at half of the phase range.
e. For more details on the external trigger output, please refer to the product manuals accessible through the red
Docs ( ) icons below.
f. The reported height dimension includes the maximum travel range of the adjuster knob.
g. Ambient temperature fluctuations may cause the characteristics of your SLM to change. Using it at an ambient
temperature of 25 °C is recommended.
