Item # EXULUS-HD2 EXULUS-HD3 EXULUS-HD4
Panel Resolution 1920 x 1200 (WUXGA)
Type Liquid Crystal on Silicon (LCoS) with Reflective Coating
Operating Wavelength 400 - 850 nm 650 - 1100 nm 1550 nm
Panel Active Area 15.42 mm x 9.66 mm
Pixel Pitch 8
µm
Fill Factor >92%
Reflective Coating Aluminum Dielectric
Average Reflectance 80% (Typical) 82% (Typical)
Phase / Retardance Range
2π at 633 nm (Full Wave Mode)
π at 633 nm (Half Wave Mode)
2π at 1064 nm (Full Wave Mode)
π at 1064 nm (Half Wave Mode)
2π at
1550 nm (Full Wave Mode)
π at 1550 nm (Half Wave Mode)
Angle of Incidence
a
0°
Optic Axis 0°
Reflected Wavefront Distortion <λ/2 @ 633 nm <0.4λ @ 633 nm
Damage Threshold
Pulsed (ns)
0.22 J/cm
2
(532 nm, 6.8 ns, 10 Hz, Ø200.5 µm)
0.15 J/cm
2
(1064 nm, 10 ns, 100 Hz, Ø235 µm)
0.187 J/cm
2
(1550 nm, 6.0 ns, 10 Hz, Ø230.6 µm)
Pulsed (fs)
0.0935 J/cm
2
(515 nm, 203.3 fs, 100 Hz, Ø108.2 µm)
0.03 J/cm
2
(1030 nm, 200 fs, 100 Hz, Ø135 µm)
0.076 J/cm
2
(1550 nm, 55.6 fs, 100 Hz, Ø143.1 µm)
Frame Rate 60 Hz
Fluctuation / Flickering (RMS)
b
<0.01% <0.05% <0.15%
Beam Deviation Using Panel Tip / Tilt ±3.2°
Trigger Output
c
SMA Female
Trigger Output High Voltage Level 5 V (TTL)
Trigger Output Pulse Width 54 µs
Dimensions (L x W x H)
d
155.9 mm x 104.3 mm x 42.0 mm (6.14" x 4.11" x 1.65")
Weight 0.76 kg (1.68 lbs)
Storage Temperature 0 °C to 60 °C (32 °F to 140 °F)
Operating Temperature
e
10 °C to 40 °C (50 °F to 104 °F)
PC Connection
HDMI-Compatible Connector
USB 2.0 Connector
Bit Depth 8 Bit, 0 - 255 Gray Level
a. Other angles of incidence will result in phase shifts that differ from the programmed pattern. Angles of up to 10° are possible without significantly affecting
performance.
b. Fluctuation / Flickering is the phase fluctuation as the percentage of the entire phase range and is dependent on current phase setting. The value stated is
the maximum fluctuation and typically occurs at half of the phase range.
c. For more details on the external trigger output, please refer to the product manuals accessible through the red Docs ( ) icons below.
d. The reported length dimension includes the maximum travel range of the adjuster knob. The specified height does not include the dust cover; when
included, this dimension is nominally 46 mm.
e. Ambient temperature fluctuations may cause the characteristics of your SLM to change. Using it at an ambient temperature of 25 °C is recommended.
Item # EXULUS-HD2HP EXULUS-HD3HP
Panel Resolution 1920 x 1200 (WUXGA)
Type Liquid Crystal on Silicon (LCoS) with Reflective Coating
Operating Wavelength 400 - 850 nm 650 - 1100 nm
Panel Active Area 15.42 mm x 9.66 mm
Pixel Pitch 8
µm
Fill Factor >92%
Reflective Coating Aluminum
