© 2021 Thorlabs
PM103x
Page 3
MTN023788_D02
1.2 Ordering Codes and Accessories
PM103
Power and Energy Meter Interface with DA-15 Connector; USB, RS232, or UART
Operation. Digital or Analog Signal Output; Two Digital I/O Ports; NTC Input; USB
Interface for Control and Power Supply.
PM103A
Power and Energy Meter Interface with SMA Connectors for two Analog Outputs
and one Digital I/O Port; USB Interface for Control and Power Supply.
PM103U
Power and Energy Meter Interface with USB Connector and USB Operation for
Control, Read Out, and Power Supply.
Included Accessories:
The PM103x Power and Energy Meters include certain cables. Further cables are recommen-
ded in Optional Accessories .
PM103: DA-15 Connector and Connector Housing
USB Cable, Type A to Mini B, with locking screw, 1.5m
PM103A: USB Cable, Type A to Mini B, with locking screw, 1.5m
PM103U: USB Cable, Type A to Mini B, with locking screw, 1.5m
Optional Accessories:
To run the PM103x power and energy meter, additional cables or mounting devices may be re-
quired.
Cables
· PM103: Cable to attach to the provided DA-15 connector housing.
· PM103A: SMA cable: please provide a cable with a SMA connector with your PM103A.
Thorlabs offers a variety of SMA connector cables.
Mounting
· Horizontal Mounting Clamp (ECM225) to mount the PM103x onto a post.
· Vertical Mounting Clamp (ECM100) to mount the narrow side of the PM103x onto a post.
· Double Sided Horizontal Mounting Clamp (EPS225) to securely mount two devices on top of
each other.
Please visit our homepage http://www.thorlabs.com for various accessories like power and en-
ergy sensors, fiber adapters, posts and post-holders.
