Page #24 background image
© 2015 Thorlabs22
TED200C
General Data
Safety Features
TEC Current Limit
Short Circuit when TEC off
Missing Sensor Protection
Open Circuit Detection
Over Temperature Protection
Display
LED, 5 Digits
Connector for Sensor, TE Cooler, TEC On
Signal:
15-pin D-Sub Jack
Connectors for Control Input / Output
BNC
Chassis Ground Connector
4mm Banana Jack
Line Voltage
100 V
115 V +15% / –10%
230 V
Line Frequency
50 to 60 Hz
Mains Supply Overvoltage
Category II (Cat II)
Maximum Power Consumption
60 VA
Operating Temperature Range
1
)
0 °C to +40 °C
Storage Temperature Range
-40 °C to +70 °C
Relative Humidity
Max. 80% up to 31 °C, decreasing to 50% at 40 °C
Pollution Degree (Indoor Use only)
2
Operation Altitude
<2000 m
Warm-up Time for Rated Accuracy
10 min
Dimensions (W x H x D)
w/o Operating Elements
with Operating Elements
146 x 66 x 290 mm³
146 x 77 x 320 mm³
Weight
<3.1 kg
1
)non-condensing
2
)Temperature Control Values for thermistors are given in W since the controlled parameter is the resistance, not
the temperature
3
)Due to the nonlinear conversion from W to °C the stability in °C depends on the operating conditions and the
characteristics of the thermistor. E.g. for a typical thermistor at a set point of 10kW (25°C), a 0.5W stability
translates into about 1mK temperature stability. At a set point of 5kW (38°C), the stability is about 2mK.
All technical data are valid at 23 ± 5°C and 45 ± 15% rel. humidity (non condensing)
