5 Appendix
5.1 Technical Data
TEC Current Output
Control Range
0 to ±2 A
Compliance Voltage
>6 V
Maximum Output Power
12 W
Measurement Resolution
1 mA
Measurement Accuracy
±10 mA
Noise and Ripple (typ.)
<1 mA
TEC Current Limit
Setting Range
0 to >2 A
Resolution
1 mA
Accuracy
± 20 mA
Thermistor Sensors
2
)
Control Range
10 W to 20 kW
100 W to 200 kW
Resolution
1 W
10W
Accuracy
±10 W
±100 W
Temperature Stability 24 hours
3
)
<0.5 W
<5 W
IC Sensors (Transducers)
Supported Sensors
AD590, AD592, LM135, LM335
Control Range with AD590, LM135
-45 °C to +145 °C
Control Range with AD592
-25 °C to +105 °C
Control Range with LM335
-40 °C to +100 °C
Resolution
0.01 °C
Accuracy
±0.1 °C
Temperature Stability 24 hours
<0.002 °C
Temperature Control Input
Input Resistance
10 kW
Control Voltage
-10 V to +10 V
Transmission Coefficient Thermistor
2 kW/V ± 5 %
20 kW/V ± 5 %
Transmission Coefficient IC-Sensors
20 °C/V ± 5%
Temperature Monitor Output
Load Resistance
>10 kW
Transmission Coefficient Thermistor
500 mV/kW ± 5 %
50 mV/kW ± 5 %
Transmission Coefficient IC-Sensors
50 mV/°C ± 5 %
