step 1.
NOTE: DO NOT fully tighten all bolts
until you finish assembling all parts.
Once assembled, go back and fully
tighten all bolts. This will make the
assembly easier.
6
The slant holes will face the floor
when the unit is turned upright
Fit the back stretcher (F) between the back legs (D and E) and attach them to the back apron of desk top (A).
(H1) x 4
2 1/2” bolt
(H2) x 4
lock washer
(H3) x 4
flat washer
A
E
D
H1
H2
H3
H1
H2
H3
F
The mortise points towards
the front of the unit
(H5) x 1
hex wrench
To Next Page
