step 2.
NOTE: DO NOT fully tighten all bolts
until you finish assembling all parts.
Once assembled, go back and fully
tighten all bolts. This will make the
assembly easier.
7
Attach the front legs (B and C) to the desk top (A) loosely and insert the side stretchers (G) between the legs properly.
A
(H1) x 4
2 1/2” bolt
(H2) x 4
lock washer
(H3) x 4
flat washer
H2
H1
H3
G
C
G
E
D
B
H2
H1
H3
The slant holes will face the floor
when the unit is turned upright
(H5) x 1
hex wrench
To Next Page
