Threshold Conway Cast - Assembly Step 4; Attach Side Frames

UP
UP
step 4.
10
NOTE: DO NOT fully tighten all bolts
until you finish assembling all parts.
Once assembled, go back and fully
tighten all bolts. This will make the
assembly easier.
(H4) x 6
1/4” x 5/8” bolt
F
A
H4
H4
B
The threaded sockets for
stretchers on opposite side
C
Turn the assembled base upright.
Align and attach the frames (A, B and C) to the assembled base.
H4
G
