Threshold Conway Cast - Assembly Step 3; Assemble Base Structure

FRONT
step 3.
Align and attach the assembled base (G, H, I and J) to the bottom panel (F).
9
H1
H3
I
H
I
G
(H1) x 12
cam lock
(H3) x 8
M8 x 30 mm wood dowel
F
NOTE: Try working from one end to
the other to slide the assembled base
into place. You may need to push or
pull the skirts or loosen the cam locks
slightly to get them to align with the
holes.
