Threshold STUDIO MCGEE TGT63BK - Step 3: Attach Roller Catch Metal Plates

10
3.1. Using the pilot holes as a guide, Fasten two roller catch metal plates (H14) to the bottom panel (C) using two 12 mm screws (H16) in each.
(H14) x 2
roller catch
metal plate
(H16) x 4
M3.5 x 12 mm
flat head screw
step 3: Attach the roller catch metal plates to the bottom panel
The projection faces forward
H14
H16
H16
H14
C
