Threshold STUDIO MCGEE TGT63BK - Step 4: Assemble Frame Components

(H1) x 6
cam lock
(H3) x 6
M8 x 30 mm wood dowel
step 4: Attach top back stretcher and bottom panel to the side frames
4.1. Attach the bottom panel (C) to the right side frame (G) using two cam locks (H1) and two wood dowels (H3).
4.2. Attach the top back stretcher (D) to the right side frame (G) using one cam lock (H1) and one wood dowel (H3).
4.3. Repeat the same procedure to attach the left side frame (F) at the opposite end.
11
G
G
C
H3
C
D
G
H1
H1
H3
D
F
F
F
The cam locks faces outward
