step 7: Install door hinges
(H11) x 6
door hinge
7.1. Align and attach the door hinges (H11) to the doors (H and I), using four 12 mm bolts (H4) per hinge as shown.
(H4) x 24
M4 x 12 mm bolt
(H18) x 1
small hex wrench
14
NOTE: DO NOT fully tighten all bolts
until you finish assembling all parts.
Once assembled, go back and fully
tighten all bolts. This will make the
assembly easier.
H11
H
I
H
I
H4
H4
To Next Page
