17
NOTE: Open and close the doors and adjust the gaps to make sure they are aligned and shut correctly.
If you find that the doors do not close properly or do not align correctly, please follow these steps:
10.1. Adjust the floor levelers pre-attached underneath the side frames (F and G) to level the doors.
10.2. The magnetic catches (H12) and the roller catch metal plates (H14) can be adjusted to ensure that the doors function properly. This can be done by
moving the catches forward and back.
10.3. Open the doors and loosen the installed screws (H16) on the door hinges (H11) and adjust properly for a good fit.
10.4. Once the doors function properly, go back and tighten all the screws.
step 10: Correct the doors alignment
Floor leveler
G
F
H11
H16
I
H12
A
H
H14
To Next Page
