Threshold TGAVC72-23 - Page 10

D
step 5: attach the top panel to the previous assembly
(H1) x 14
cam lock
(H3) x 12
M8 x 30 mm
wood dowel
10
5.1. Insert twelve 30mm wood dowels (H3) into the top inner holes of the panels (D, G and H).
5.2. Align and attach the top panel (A) to the previous assembly using fourteen cam locks (H1).
G
H
H
H1
H3
A
A
D
