Threshold TGAVC72-23 - Page 9

D
step 4: attach the middle partitions to the base
9
(H1) x 4
cam lock
(H3) x 4
M8 x 30 mm
wood dowel
4.1. Insert two 30mm wood dowels (H3) into the bottom inner holes of each middle partition (D).
4.2. Align and attach the middle partitions (D) to the base (C) with four cam locks (H1).
C
H3
H1
C
D
D
