Threshold TGAVC72-23 - Page 8

step 3: attach the previous assembly to the base
8
(H1) x 10
cam lock
(H3) x 8
M8 x 30 mm
wood dowel
3.1. Insert eight 30mm wood dowels (H3) into the bottom inner holes of the panels (H and G).
3.2. Align and attach both side panels (H) and back panel (G) to the base (C) with ten cam locks (H1).
G
H
H
G
H
C
H1
H3
C
Floor leveler
The floor protector
H1
