Threshold TGAVC72-23 - Page 7

step 2: attach the back panel between the side panels
7
2.1. Insert four 30mm wood dowels (H3) into the side holes of the back panels (G) at both ends.
2.2. Align and attach the back panels (G) between the side panels (H) with eight cam locks (H1).
(H1) x 8
cam lock
(H3) x 4
M8 x 30 mm
wood dowel
G
H
H
H1
H3
G
The cam locks face inward
