Threshold TGAVC72-23 - Page 12

12
step 7: install the adjustable shelves
7.1. Insert four shelf supports (H4) into the desired holes in the sides of each compartment. Make sure you place the four shelf supports at the same level so the
shelf is not tilted.
7.2. Tilt and rest the adjustable shelves (B and I) onto the shelf supports. Secure the shelf in place with the 12mm screws (H7) for extra support.
(H4) x 12
shelf support
(H7) x 12
M3.5 x 12 mm screw
H
D
H
H4
B
B
H7
I
B
D
