Thrustmaster dual trigger - PlayStation 2 Setup and Modes; Installation on PlayStation 2

2/10
TABLE OF SUPPORTED MODES
Platform MODE MODE button color (8)
PLAYSTATION®1
PS1 OFF
PLAYSTATION®2 PS2 RED
PLAYSTATION®3 PS3 RED
PC
4 AXES GREEN
6 AXES RED
PLAYSTATION®2
INSTALLATION ON PLAYSTATION®2
1. Connect the PS2 Gameport connector (11) to a number 1 port on your console.
2. Turn on your console and start up your game.
You are now ready to play!
ATTENTION: NEVER CONNECT THE USB CABLE (10) TO YOUR PLAYSTATION®2
(to avoid the risk of damaging your gamepad or your console)
PLAYSTATION®2 MODE
 PS1 mode: the MODE button is off (reserved exclusively for Playstation®1 games)
 PS2 mode: the MODE button is red (reserved exclusively for Playstation®2 games)
AUTOMATIC PRESET CONFIGURATION - PLAYSTATION®2
PS2 mode MODE button is RED
Here:
 Right trigger associated with progressive
Cross button
 Left trigger associated with progressive
Square button
