ATTACHING THE PEDAL SET TO A SUPPORT OR COCKPIT
The pedal set can be attached to a variety of different compatible supports (sold separately) using the
five M6-type threaded holes located underneath the base. To do so, screw at least two M6 screws (not
included) through the support shelf, and into the threaded holes on the underside of the pedal set’s
base.
Important: the length of the M6 screws must not exceed the thickness of your support by more than
0.47 inches/12 mm, so as not to risk damaging the pedal set’s internal components.
The pedal set’s setup diagrams for cockpits and other supports are available at
https://support.thrustmaster.com: click Racing Wheels / T3PM, and then Template - Cockpit
setup.
