0. Installation
Please ensure carefully that all following rules are complied to; otherwise you may void
your warranty and Thule Audio will accept no responsibility for any damages incurred:
- Place the amplifier on a hard and flat surface.
- The ventilation holes should not be covered. There must be at least 10 cm (4
inches) of free air on top of the amplifier. Do not place any other equipment on top
of the amplifier.
-
Do not expose the amplifier to direct sunlight.
-
Do not place the amplifier in warm or dusty environments.
Caution: Because of risk of fire or electric shock, do not expose the amplifier to rain or
moisture.
Caution: Because of risk of electric shock, do not open the amplifier.
1. Input selection
The input selection is very flexible, so it can suit many different home theatre and
stereo installations. It is possible to switch between seven different inputs, which are
directly accessed by keys on the front panel (only AV120) or on the remote control.
Each input can be configured in different ways, shown below with an “X”.
The factory settings are marked with [ ] brackets. Changes to this setting can be
made in the config menu.
INPUTS
DVD
SAT
LD
TV
Tape 1
Tape 2
Pure A.
Analogue
X
X
[X]
[X]
[X]
Coax digital
[X]
[X]
[X]
X
Dig. Direct
X
Optical
X
[X]
Composite
[X]
X
[X]
X
S-video
X
X
[X]
X
[X]
Component
[X]
X
For audio signals, one of four options in the upper three rows must be selected
under the config.input menu.
Similarly, the video inputs configuration must be selected for AV100S/AV120S in the
config.video-input-output menu. After video switching, the built-in adaptive comb
filter converts the selected video source into component or RGB video format.
Therefore, your projector or TV must be set correctly to either RGB or component,
and the “intelligent” video switching in AV100S/120S will take of the rest.
The Pure Audio input will bypass the DSP circuits and is recommended for high
quality music listening in stereo e.g. to a CD player or another analogue source.
Alternatively, for high quality music listening in stereo, connect the digital output from
a CD player or DVD player to one of the available digital inputs in the AV100/120
