Thule 9031XT - Page 10

506-7079
12
CLO
SING CARRIER
- A. Remo
ve hold-open pin. Pull lock up pin to release upper arm assembly and rotate bike arms to stop position.
- B. Close carrier. L
ock-up pin will click into closed position.
- Tight
en lower locking handle firmly.
- WARNING: Before operating your vehicle, tighten locking handle firmly.
B
A B
lock-up pin
low
er locking handle
