Thule BSTK2 - Installation Steps 1 b & 2; Attaching Base Support Brackets; Connecting Structure Halves

•
Attach the two base support brackets (N) as shown. Thread the shorter hex
head screws (F) through the washers (H) and then into both the structure
bottom leg (K) and the foot base (M). Tighten firmly.
1b
F
H
K
M
N
• Slide the structure top half (J) onto the tops of the structure bottom legs as
shown.
The Thule logo should be facing forward.
2
J
K
