5015829_04
LOCK CYLINDER INSTALLATION FOR STL2
a. Remove and discard plug. b. Open cover.
c. Insert change key
into lock cylinder-
d. Insert cylinder into
STL2 lock housing.
e. Remove change key.
Insert locking key.
11
• Slide STL2 onto hitch pin, keeping key vertical.
• Turn key clockwise to lock, remove key.
• Close cover.
INSTALLATION OF STL2
