THUNDER TIGER ECUREUIL AS355 - Parts Drawings; PV6039 Fuselage Parts; PV6040 Windshield Parts; PV6041 Decoration Set Parts

Front Fuselage (1)
Rear Fuselage (1)
2x8mm
Wood Screw (16)
Horizontal Tail (1)
Exhaust Pipe (2)
Tail Transmission
Case Cover (1)
PV6039 Fuselage
PV6040 Windshield
Front Windshield (1)
Front Window L/1,R/1
Rear Window L/1,R/1
Sunroof L/1,R/1
Front Lower Window L/1,R/1
Bottom Window L/1,R/1
Air Inlet L/1,R/1
2x5mm Wood Screw (52)
3x23mm
Socket Screw (2)
Battery Tray (1)
Rubber Band (2)
Doubler (16)
PV6041 Decoration Set
Wiper (2)
L/F Antenna (2)
H/F Antenna (4)
Tail Skid (1)
PV6042 Foam Retainer
Tail Boom
Foam Retainer (1)
PV6043 Retaining Set
Post (2)
Silicon Grommet (2)
3x10mm
Washer Screw (2)
M2 Nut (2)
PV6044 Landing Skid
Brace A (1)
Brace B (1)
Skid Pipe (2)
Wiper Strut (2)
Pitot Tube (2)
Skid Adaptor (F,2)
Skid Joiner (4)
Skid Pipe
End Cap (2) M3 Locknut (5)
3x4mm
Setscrew (10)
Front Mounting
Strip (2)
Step Bar (1)
Step Ladder (1)
Skid Adaptor (R,2)
Step Bar
Retainer (1) Foam Tape (8)
Wiper Mount (2)
Handlebar (4) LED (1)
Retaining
Collar (18)
2x6mm Screw (2)
2.3x12mm Washer
Wood Screw (1)
3x15mm
Self-tapping
Screw (4)
2x5mm
Wood Screw (1)
3x15mm
Screw (1)
3x30mm
Socket Screw (2)
3x14mm
Socket Screw (2)
3x20mm
Self-tapping
Screw (4)
Plastic Tube(1)
Rear Mounting
Strip (L/1,R/1)
54
PARTS DRAWINGS PARTS DRAWINGS
ECUREUIL AS355ECUREUIL AS355
