Thunderbolt 3 - Front Thunderbolt 3 Solution; Front Thunderbolt 3 Parts List

3
Front Thunderbolt 3 solution
The front Thunderbolt 3 solution provides two ports on the front of your ThinkStation.
Parts list
The following parts are needed for the installation of the front Thunderbolt 3 solution:
 5.25” FLEX Module (FRU 01EF759)
 Front Thunderbolt bezel (FRU 01EF100)
 Circuit board bracket (FRU 01EF160)
 Thunderbolt 3 PCIe x4 card kit (FRU 01YW003)
 PCIe x4 adapter card
 External DP to DP cable
 Front Panel IO board and cable kit (FRU 01YW016)
 Front panel IO circuit board
 General purpose input/output (GPIO) cable
 Mini-SAS cable
 Internal DP to DP cable
FLEX module
PCIe x4 adapter card
External DP to DP cable (200mm)
